La Galleria delle Applicazioni raccoglie un'ampia varietà di tutorial e di app dimostrative realizzati con COMSOL Multiphysics in diversi ambiti applicativi, inclusi quelli elettrico, meccanico, fluidico e chimico. E' possibile scaricare i file dei modelli e delle app demo pronti all'uso e le istruzioni step-by-step per costruirli, e utilizzarli come punto di partenza per le proprie simulazioni.
Lo strumento di Ricerca Rapida permette di trovare i modelli che si riferiscono alla propria area di interesse.
Si noti che molti degli esempi qui presentati sono accessibili anche tramite le Librerie delle Applicazioni incorporate nel software COMSOL Multiphysics® e disponibili dal menu File.
This example demonstrates how to apply inverse uncertainty quantification (IUQ) using the Uncertainty Quantification (UQ) Module in COMSOL Multiphysics to calibrate uncertain material properties of a resistor based on measurement data. When experimental data such as resistance values are ... Per saperne di più
In semiconductor manufacturing, vacuum chucks are used to rapidly and contamination-free adsorb and secure wafers before processes such as transfer, lithography, and inspection. Traditional empirical design makes it difficult to quantify the effects of groove shape, size, distribution, ... Per saperne di più
In direct bonding, if the interface is not clean and particles are present, even particles on the micron scale can significantly degrade the bonding quality, resulting in large-area voids. This model demonstrates the simulation process of 3D D2W direct bonding, taking into account the ... Per saperne di più
This app generates random surfaces based on imported CAD models. Surfaces can be created using Gaussian or uniform random fields, analytical expressions, or combinations of random and deterministic fields. The app provides extensive customization options for controlling roughness, ... Per saperne di più
This example demonstrates how to model a variable-angle tow (VAT) laminate in which the fiber orientation varies linearly along the global x-direction, with each layer assigned its own fiber angle. The results obtained using the Layered Shell interface are compared with a full 3D ... Per saperne di più
This example demonstrates the optimization of fiber orientation in a variable angle tow (VAT) laminate to maximize stiffness under prescribed loading and boundary conditions. The composite laminate consists of a single layer of carbon–PEEK composite with transversely isotropic material ... Per saperne di più
In electrosurgery, high-power AC current from a probe is driven into tissue in order to cut and coagulate it. The current causes rapid Joule heating near the tip, and as temperatures reach 100°C, water and blood vaporize and the tissue desiccates, enabling cutting or sealing. This ... Per saperne di più
PCB is fabricated by laminating multiple materials, such as FR-4, copper, and resin, which exhibit significantly different coefficients of thermal expansion (CTE). When subjected to heating, the differential thermal expansion among these layers induces interlaminar deformation mismatch, ... Per saperne di più
This model demonstrates isoelectric focusing (IEF) of seven ampholytes in a column. The model is in 1D and is solved in a time-dependent simulation. Per saperne di più
Galvanostatic Intermittent Titration Technique (GITT) is commonly used to estimate the solid-phase lithium diffusion coefficient in electrode particles. In this example, a half-cell model is built using the Lithium-Ion Battery interface, and imported synthetic voltage datasets at ... Per saperne di più
