La Galleria delle Applicazioni raccoglie un'ampia varietà di tutorial e di app dimostrative realizzati con COMSOL Multiphysics in diversi ambiti applicativi, inclusi quelli elettrico, meccanico, fluidico e chimico. E' possibile scaricare i file dei modelli e delle app demo pronti all'uso e le istruzioni step-by-step per costruirli, e utilizzarli come punto di partenza per le proprie simulazioni.

Lo strumento di Ricerca Rapida permette di trovare i modelli che si riferiscono alla propria area di interesse. Per scaricare i file .mph dei modelli è necessario effettuare il login o creare un account COMSOL Access associato a un numero di licenza valido.

COMSOL-News-Magazine-2017
COMSOL-News-Magazine-2017-Special-edition-acoustics
COMSOL-News-Magazine-2016

The Brüel & Kjær 4134 Condenser Microphone

This is a model of the Brüel and Kjær 4134 condenser microphone. The geometry and material parameters are those of the actual microphone. The modeled sensitivity level is compared to measurements performed on an actual microphone and shows good agreement. The membrane deformation, pressure, velocity, and electric field are also determined. The model is a true multiphysics problem that ...

Piezoelectric Tonpilz Transducer

The tonpilz (sound mushroom) piezoelectric transducer is a transducer for relatively low frequency, high power sound emission. The transducer consists of piezoceramic rings stacked between massive ends and pre-stressed by a central bolt. The tail and head mass lower the resonance frequency of the device. In this model the frequency response of the transducer when the bolt is not pre-stressed ...

Acoustic Transmission Loss through Periodic Elastic Structures

In this model, two fluids are separated by a solid elastic structure. An acoustic pressure wave impacts the structure resulting in a reflected wave and a wave transmitted with a loss through the structure. This model investigates the transmission loss through the structure. The effects of incident angle, frequency, and dampings are studied. Important features used: Acoustic-structure ...

Acoustic-Structure Interaction with a Perfectly Matched Layer (PML)

This small tutorial model shows how to set up a model with a solid mechanics and a pressure acoustics domain including a common perfectly matched layer (PML). The PML is used to model an open or infinite domain for both the elastic waves and the pressure waves. Two configurations of PMLs exist (this model describes the first case which is also the most difficult to handle): 1. One PML should ...

Absorptive Muffler

The sound level from a car depends to a great extent of the quality of the muffler. Over the years, researchers in the car industry have struggled to produce mufflers that are efficient from both an acoustic and an environmental perspective. This model describes the pressure wave propagation in a muffler for an internal combustion engine. The model also shows how to analyze both inductive and ...

Sedan Interior Acoustics

This is a model of the acoustics inside a sedan, that is inside a typical hard-top family car. The model sets up sources at loudspeaker locations as well as impedance conditions to model soft absorbing surfaces (seats and carpet). The model results in plots of the pressure, sound pressure level, and intensity inside the car. The frequency response at given points inside the cabin are also ...

Acoustic Streaming in a Microchannel Cross Section

Recent advances in the fabrication of microfluidic systems require handling of live cells and other micro particles as well as mixing. All this can, for example, be achieved using acoustic radiation forces and the viscous drag from the streaming flow. Streaming: Due to the nonlinear terms in the Navier-Stokes equations, harmonic perturbation of the flow will lead to a net time-averaged flow ...

One-Family House Acoustics

This model shows an application of the Acoustic Diffusion Equation physics interface. The acoustics in a two story one-family house consisting of 10 rooms is analyzed. The steady state sound pressure level (acoustic energy density) distribution is analyzed for a sound source located in the main living room. The reverberation time T60 of the different coupled rooms is then studied using the ...

Loudspeaker Driver in a Vented Enclosure

This model of a boxed loudspeaker lets you apply a nominal driving voltage and extract the resulting sound pressure level in the outside room as a function of the frequency. The sensitivity, both on-axis and spatial, is determined as function of frequency. These are some of the most important design parameters for a loudspeaker. The electromagnetic properties of the driver are supplied from the ...

Acoustic Levitator

An ultrasonic standing wave levitator, also called acoustic levitator, is a device used for levitating fluid and solid particles in an acoustic field. The standing acoustic waves exert an acoustic radiation force on the particles. The force is a second order effect and stems from a combination of the time averaged pressure and inertial interaction between the particles and the acoustic field. ...
