Eddy Currents in a Cylinder

Application ID: 128

An AC coil surrounding a metal cylinder induces eddy currents in the cylinder. The driving current in the coil can be specified in two ways: either as an external current density or as equivalent surface currents. In the first case, the skin effect can be studied by giving the coil a non-zero conductivity.

Questo modello è stato realizzato con:

AC/DC Module
