In questa sezione troverete i lavori presentati alle Conferenze mondiali COMSOL. Le presentazioni descrivono ricerche e prodotti innovativi progettati con COMSOL Multiphysics da colleghi di tutto il mondo. I temi delle ricerche presentate abbracciano un'ampia gamma di settori produttivi e aree applicative, in ambito elettrico, meccanico, fluidodinamico e chimico. Lo strumento di Ricerca Rapida vi permetterà di trovare le presentazioni che si riferiscono all'area di vostro interesse.

Study of Effect on Resonance Frequency of Piezoelectric Unimorph Cantilever for Energy Harvesting

G. R. Prakash[1], K. M. V. Swamy[1], S. Huddar[1], B. G. Sheeparamatti[1], Kirankumar B. B.[1]
[1]Basaveshwar Engineering College, Bagalkot, Karnataka, India

The focus of this paper is to study the effect on resonance frequency and power enhancement techniques[1] of piezoelectric MEMS and modeling, design, and optimization of a piezoelectric generator based on a two-layer bending element(Figure 1) using COMSOL Multiphysics. An analytical relation was developed based on the shift in resonance frequency(Figure 2) caused by the addition of a thin film ...

Simulations of MEMS Based Piezoresistive Accelerometer Designs in COMSOL

N. Bhalla[1], S. Li[2], and D. Chung[1]
[1]Chung Yuan Christian University, Taiwan, (R.O.C)
[2]National Tsing Hua University, Taiwan, (R.O.C)

Different configurations of MEMS based accelerometer has been made and analysed using COMSOL Multiphysics. The designs presented in this paper consist of a square shaped proof mass with flexures supporting it. Different position and varied number of supporting flexures attached to the proof mass makes each configuration distinct. The piezoresistors are placed near the proof mass and frame ends ...

Design and Analysis of MEMS Gyroscope

L. Sujatha[1], B. Preethi[1]
[1]Rajalakshmi Engineering College, Chennai, India

MEMS gyroscope technology provides cost- effective method for improving directional estimation and overall accuracy in the navigation systems. This paper presents a tuning- fork gyroscope (TFG) [1] with a perforated proof mass. The perforated proof mass used in the design enables the reduction of the damping effect. This MEMS based gyroscope was designed using COMSOL Multiphysics 4.2a. This ...

Sensitivity Analysis of Different Models of Piezoresistive Micro Pressure Sensors

S. Meenatchisundaram[1], S. M. Kulkarni[2], S. Bhat
[1]Department of Instrumentation and Control Engineering, Manipal Institute of Technology, Manipal, Karnataka, India.
[2]Department of Mechanical Engineering, National Institute of Technology, Surathkal, Karnataka, India.

Piezoresistive pressure sensors have received much attention over the years because of low cost, simple measurement techniques, etc. There is a challenge in design with respect to appropriate positioning, shape and temperature compensation. Different models of piezoresistive pressure sensors are proposed to enhance its sensitivity in terms of output voltage. This paper aims in sensitivity ...

Surface Plasmon Resonance

J. Crompton[1], S. Yushanov[1], L.T. Gritter[1], K.C. Koppenhoefer[1]
[1]AltaSim Technologies, Columbus, OH, USA

The resonance conditions for surface plasmons are influenced by the type and amount of material on a surface. Full insight into surface plasmon resonance requires quantum mechanics considerations. However, it can be also described in terms of classical electromagnetic theory by considering electromagnetic wave reflection, transmission, and absorption for the multi-layer medium. The two commonly ...

CVD Graphene Growth Mechanism on Nickel Thin Films - new

K. Al-Shurman[1], H. Naseem[2]
[1]The Institute for Nanoscience & Engineering, University of Arkansas, Fayetteville, AR, USA
[2]Department of Electrical Engineering, University of Arkansas, Fayetteville, AR, USA

Chemical vapor deposition is considered a promising method for synthesis of graphene films on different types of substrate utilizing transition metals such as Ni. However, synthesizing a single-layer graphene and controlling the quality of the graphene CVD film on Ni are very challenging due to the multiplicity of the CVD growth conditions. COMSOL Multiphysics® software is used to investigate ...

A Study of Thermal Stress Distribution Produced During MEMS Packaging

V. Sharma[1], A. K. Jayanthy[1], J. G. Baruah[1], J. V. Prabhu[1], K. Balakrishnan[1]
[1]SRM University, Chennai, Tamil Nadu, India

The analysis performed is categorized into two levels: 1. The thermal stress distribution on the sensing part with the variation in the substrate three glass material with appropriate dimensions and exposures. The reason behind this consideration of different materials is test the compatibility with the crystal. This variation in substrate material and its material properties shows which is ...

Tunable MEMS Capacitor for RF Applications

H. S. Shriram[1], T. Nimje[1], D. Vakharia[1]
[1]BITS Pilani, Rajasthan, India

Radio Frequency MEMS devices have emerged to overcome the problem of high losses associated with semiconductors at high frequencies. A tunable MEMS capacitor is a micrometre-scale electronic device whose capacitance is controlled through different actuation mechanisms which govern the moving parts. It can have electrostatic or electrothermal actuators depending on the functional complexity and ...

Three-Dimensional Modeling of Electrical Scanning Probe Microscopy Problems

G. Gomila [1], L. Fumagalli [2], R. Fabregas [3],
[1] Institut de Bioenginyeria de Catalunya (IBEC), Departament d’Electrònica, Universitat de Barcelona, Barcelona, Spain
[2] School of Physics and Astronomy, University of Manchester, Manchester, United Kingdom
[3] Institut de Bioenginyeria de Catalunya (IBEC), Universitat de Barcelona, Barcelona, Spain

Electrical scanning probe microscopy (SPM) techniques, such as electrostatic force microscopy, nanoscale impedance microscopy or scanning near field microwave microscopy, are a relatively new branch of microscopy techniques that can generate images of the nanoscale electrical properties of samples (conductivity, permittivity, charge, etc.). These techniques scan the surface of a sample ...

Design of a MEMS Capacitive Comb-drive Accelerometer

T. Kaya[1], B. Shiari[2], K. Petsch[1], and D. Yates[2]
[1]Central Michigan University, School of Engineering and Technology, Mount Pleasant, MI
[2]University of Michigan, Dept. of Electrical Engineering and Computer Science, Ann Arbor, MI

In this work, a MEMS low-g accelerometer with three sensitive directions is designed for health monitoring applications. The accelerometer may have different sensitivity in different axes. The proof-mass of the device is suspended by four serpentine springs, and the comb drive structure is used to form the differential capacitor to measure the displacement of the proof-mass. The structure has an ...

1 - 10 of 395 First | < Previous | Next > | Last
