In questa sezione troverete i lavori presentati alle Conferenze mondiali COMSOL. Le presentazioni descrivono ricerche e prodotti innovativi progettati con COMSOL Multiphysics da colleghi di tutto il mondo. I temi delle ricerche presentate abbracciano un'ampia gamma di settori produttivi e aree applicative, in ambito elettrico, meccanico, fluidodinamico e chimico. Lo strumento di Ricerca Rapida vi permetterà di trovare le presentazioni che si riferiscono all'area di vostro interesse.

Optimizing the Performance of MEMS Electrostatic Comb-Drive Actuator with different Flexure Springs

S. Gupta[1], T. Pahwa[1], R. Bansal[1], V. Bansal[1], B. Prasad[1], D. Kumar[1]
[1]Electronic Science Department Kurukshetra University, Kurukshetra, Haryana

A new design of electrostatic comb drive actuator is presented in this paper by using different spring designs and with different folded beam lengths. An increased displacement of lateral comb drive actuator will subsequently be accomplished with the same actuation voltage. Stress distribution over different spring designs are simulated by COMSOL 3.5a using a standard comb drive with 4 movable ...

Nanowire Based Flexible Piezoelectric Sensor for Structural Health Monitoring Applications

A. El Kacimi [1], E. Pauliac-Vaujour [1], J. Eymery [2]
[1] University Grenoble Alpes, CEA, LETI, MINATEC Campus, Grenoble, France
[2] University Grenoble Alpes, CEA, Grenoble, France

We report on the modeling of flexible piezoelectric capacitive sensor based on GaN wires grown by Metal Organic Vapor Phase Epitaxy. Single crystal cone-shaped wires with hexagonal cross section are embedded within dielectric layers (parylene) in between two metal electrodes to achieve a capacitive structure. The device characteristics directly depend on growth conditions for example by tuning ...

Finite Element Simulation of a Surface Acoustic Wave Driven Linear Motor

B. Behera [1], H. B. Nemade [1], S. Trivedi [1],
[1] Indian Institute of Technology Guwahati, Guwahati, Assam, India

The paper presents finite element simulation of a surface acoustic wave (SAW) linear motor. The function of SAW linear motor depends on the principle of friction drive provided by SAW propagating on a piezoelectric substrate. The SAW motor comprises of a slider driven by Rayleigh wave generated on a piezoelectric stator using an interdigital transducer (IDT) fabricated on surface of the stator. ...

Modeling and Analysis of Thermal Bimorph using COMSOL Multiphysics®

Rachita Shettar[1], Dr. B G. Sheparamatti[1]
[1]Basaveshwar Engineering College, Bagalkot, Karanataka, India

In this paper modeling and simulation results of a thermal bimorph is capable of producing increased displacement for increasing temperatures are presented. Thermal bimorphs are popular actuation technology in MEMS (Micro-Electro-Mechanical Systems). Bimorph actuators consist of two materials with different coefficients of thermal expansion. The main objective of this work is to investigate the ...

Design of a MEMS Capacitive Comb-drive Accelerometer

T. Kaya[1], B. Shiari[2], K. Petsch[1], and D. Yates[2]
[1]Central Michigan University, School of Engineering and Technology, Mount Pleasant, MI
[2]University of Michigan, Dept. of Electrical Engineering and Computer Science, Ann Arbor, MI

In this work, a MEMS low-g accelerometer with three sensitive directions is designed for health monitoring applications. The accelerometer may have different sensitivity in different axes. The proof-mass of the device is suspended by four serpentine springs, and the comb drive structure is used to form the differential capacitor to measure the displacement of the proof-mass. The structure has an ...

Extraction of Electrical Equivalent Circuit of One Port SAW Resonator Using FEM-based Simulation

A. K. Namdeo [1], H. B. Nemade [1],
[1] Department of Electronics and Electrical Engineering, Indian Institute of Technology Guwahati, Guwahati, Assam, India

The paper presents a method of extraction of electrical equivalent circuit of a one port surface acoustic wave (SAW) resonator from the results of simulation based on finite element method (FEM) using COMSOL Multiphysics software. A one port SAW resonator consists of large number of periodic interdigital transducer (IDT) electrodes fabricated on the surface of a piezoelectric substrate. A ...

Calculation of Surface Acoustic Waves on a Piezoelectric Substrate using Amazon™ Cloud Computing

U. Vogel [1], M. Spindler [1], S. Wege [1], T. Gemming [1]
[1] Leibniz Institute for Solid State and Materials, Dresden, Germany

In this work, we seek to simulate SAWs for a better understanding and to benchmark the currently available cloud computing possibilities of COMSOL Multiphysics® software. By using the MEMS module we demonstrate 3D models with reduced geometry to achieve principle information about the wavefield. For a benchmark, a high-speed workstation with limited memory (RAM) is compared to the most potent ...

MEMS Resonator for RF Applications

V. Harshey
Visvesvaraya National Institute of Technology
Maharashtra, India

Vibrating mechanical tank components, such as quartz crystals and surface acoustic wave (SAW) resonators with Q’s in the range of 10e3–10e6, are widely used to implement high-Q oscillators and band pass filters in the radio frequency (RF) and intermediate frequency (IF) stages of communication transceivers. This paper will discuss designing of resonator and effects of various parameter on the ...

MEMS Electrostatic Acoustic Pixel

A. Arevalo [1], D. Conchouso [1], D. Castro [1], I. G. Foulds [2],
[1] Computer, Electrical, & Mathematical Sciences & Engineering, King Abdullah University of Science and Technology, Thuwal, Saudi Arabia
[2] The University of British Columbia, School of Engineering, Vancouver, BC, Canada

The growth of the electronics industry demand better components for the electronic systems. Such components need to be improve to keep up with the evolution of the digital era. The loudspeaker design has not been changed for almost a century [1-5]. The acoustic transducer is the last analogue component needed for a true digital audio system. We want to validate the feasibility of using an ...

Design of MEMS Based High Sensitivity and Fast Response Capacitive Humidity Sensor

R. Karthick, S. P. K. Babu, A. R. Abirami, and S. Kalainila
Periyar Maniammai University
Periyar Nagar
Vallam, Thanjavur
Tamilnadu, India

This paper presents the design and simulation of high sensitivity and fast response capacitive humidity sensor. Generally, the capacitive humidity sensor is made up of parallel electrode, the upper electrode being a grid with various line width and line spacing. A model is simulated using COMSOL Multiphysics. High sensitivity and fast response of the model is optimized by varying the ...
