Presentazioni e Articoli Tecnici

In questa sezione troverete i lavori presentati alle Conferenze mondiali COMSOL. Le presentazioni descrivono ricerche e prodotti innovativi progettati con COMSOL Multiphysics da colleghi di tutto il mondo. I temi delle ricerche presentate abbracciano un'ampia gamma di settori produttivi e aree applicative, in ambito elettrico, meccanico, fluidodinamico e chimico. Lo strumento di Ricerca Rapida vi permetterà di trovare le presentazioni che si riferiscono all'area di vostro interesse.

FEM Simulation of Generation of Bulk Acoustic Waves and their Effects in SAW Devices

A.K. Namdeo[1], N. Ramakrishnan[2], and H.B. Nemade[1]
[1]Department of Electronics and Communication Engineering, Indian Institute of Technology Guwahati, Guwahati, India
[2]Centre for Nanotechnology, Indian Institute of Technology Guwahati, Guwahati, India

This paper presents finite element method (FEM) simulation study of the generation of bulk acoustic waves (BAWs) and their effect on the performance of surface acoustic wave (SAW) devices, using COMSOL Multiphysics. A SAW delay line structure using YZ-cut lithium niobate substrate is simulated. The radiation of the bulk waves in all angles into the interior of the substrate is analyzed. The bulk ...

AlN/ZnO/Silicon Structure Combining Surface Acoustic Waves And Waveguiding Layer Acoustic Wave

O. Legrani[1], O. Elmazria[1], S. Zhgoon [2], L. Le Brizoual[3], and A. Bartasyte[1]
[1]Institut Jean Lamour, CNRS-Nancy University, Vandoeuvre lès Nancy, France
[2]Moscow Power Engineering Institute, Krasnokazarmennaja, Moscow, Russia
[3]Institut des Matériaux Jean Rouxel, Université Nantes, CNRS, Nantes, France

In this work, the theoretical study for the realization of waveguiding layer acoustic waves devices based on AlN/IDT/ZnO/Silicon structure using the modeling software COMSOL Multiphysics (2D) is presented. The effect of thicknesses of AlN and ZnO thin films on the evolution of frequency response, phase velocity and electromechanical coupling is studied. The adequate structure is determined for ...

Support-Q Optimisation of a Trapped Mode Beam Resonator - new

T. H. Hanley[1], H. T. D. Grigg[1], B. J. Gallacher[1]
[1]Newcastle University, Newcastle-Upon-Tyne, UK

Introducing a disorder into a finite periodic oscillatory system induces the presence of a 'trapped mode': a mode in which the displacement field is localised to the region of the disorder. A main inhibitor to MEMS resonators achieving a high quality (Q) factor is energy radiation through the support to the substrate. The trapped modes present a way to tune this to a minimal value. An initial ...

Analysis of Sound Propagation in Lined Ducts by Means of a Finite Element Model

D. Borelli[1] and C. Schenone[1]
[1]DIPTEM, University of Genova, Genova, Italy

The present paper describes the results of a Finite Element Model used to analyze sound propagation in lined ducts. By means of a numerical model it was possible to predict the insertion loss inside rectangular lined ducts in a frequency range from 250 Hz to 4000 Hz. The model was validated by a comparison with experimental data obtained in accordance to ISO 11691 and ISO 7235 standards. The ...

Modeling the response of photoacoustic gas sensors

S.L. Firebaugh[1], F. Roignant[2], and E.A. Terray[3]

[1]United States Naval Academy, Annapolis, Maryland, USA
[2]Polytechnique Nantes, Nantes, France
[3]Woods Hole Oceanographic Institution, Woods Hole, Massachusetts, USA

A fast, high-sensitivity detector is required for studies of environmentally relevant gases. Photoacoustic spectroscopy (PAS), an absorption spectroscopy technique in which absorption is detected as sound, is explored as a possible solution. A tuning-fork based PAS sensor is modeled using COMSOL. The model combines the acoustic and piezoelectric modules and also includes viscous damping. The ...

Acoustic Emission Simulation for Online Impact Detection

C. Yang, M. A. Torres-Arredondo, and C.-P. Fritzen
Institute of Mechanics and Control Engineering
Mechatronics
University of Siegen
Siegen, Germany

Impact monitoring has been extensively studied by several researchers and it has been shown that damage extent can be correlated with the impact magnitude. In order to make the process cost-effective, simulation of the impact has been performed, to get the big training data set from modeling. The structural dynamic responses captured by PZT transducers due to impact events are recorded from ...

Using COMSOL to Support a Cost-Effective, Non-Destructive Evaluation Approach for Predicting Bolt Failure in Highway Bridges

A. Elyea, B. Doubek, G. Hubbard, and D. Ozevin
Department of Civil Engineering
University of Illinois at Chicago
Chicago, IL

The development of a quantitative nondestructive evaluation method, as an alternative to visual inspection, for inspecting pre-tensioned bolts in fracture critical bridges is presented. In order to understand the ultrasonic behavior of a wide variety of bolt geometries used in bridges, numerical models of nine different bolt geometries were developed. The numerical models included the ...

Improving the Performance of Hearing Aids Using Acoustic Simulations

Mads Jakob Herring Jensen
Dr., Widex A/S, Denmark

In modern hearing aids, the performance of directional microphone systems is dependent on both the acoustics around thehearing aid and on the specific signal processing algorithms. The sound pressure at the microphone inlets depends on microphone location in the hearing-aid shell, the inlet shape, and on the placement of the hearing aid on the head of the user. In the present work, the ...

Transient Heat Transfer Effects from a Flapping Wing

Lind, R.J., Abedian, B.
Department of Mechanical Engineering Tufts University, Medford, Massachusetts

This presentation is a numerical study of fluid flow around a two-dimensional rigid flapping plate and its effects on the resultant transient heat transfer effects on the solid interface. In this study, a flat inflexible thin plate surrounded by air undergoes sinusoidal angular motion from one end while the other end is kept stationary, simulating a flapping motion. The two-dimensional ...

Application of COMSOL to Acoustic Imaging

K. Mcilhany, and J.C Hernandez
U.S. Naval Academy, Annapolis, MD, USA

Acoustic Imaging of hand movement is being studied with COMSOL and Matlab. A hardware implementation is being pursued that will be an array of 16x16 ultra-sonic speakers placed in a grid facing a similar grid of 16x16 microphones, operating at 40kHz. COMSOL is used to repeatedly calculate the diffraction pattern from a small scattering center, approximately 1.0cm in diameter. In conjunction ...
