Busbar with Surface-to-Surface Radiation

Application ID: 76141


This model computes an electromagnetic-heated busbar with surface-to-surface radiation and compares the results with the busbar model without radiation.

The surface emissivity of copper is varied between 0.1 (blank material), 0.3 (partially oxidized), and 0.7 (heavily oxidized).

A more detailed description of this model can be found in the blog post: The Importance of Thermal Radiation in Your Models.

This model example illustrates applications of this type that would nominally be built using the following products:
