Adjusting the Element Size for the Unstructured Mesh Generator

Application ID: 14439

This is a tutorial model that demonstrates how to use mesh parameters such as

  • Minimum element size
  • Resolution of curvature
  • Resolution of narrow regions
  • Maximum element growth rate

The instructions also detail how to access the mesh statistics and how to create a mesh plot.

This model example illustrates applications of this type that would nominally be built using the following products:
