Presentazioni e Articoli Tecnici

In questa sezione troverete i lavori presentati alle Conferenze mondiali COMSOL. Le presentazioni descrivono ricerche e prodotti innovativi progettati con COMSOL Multiphysics da colleghi di tutto il mondo. I temi delle ricerche presentate abbracciano un'ampia gamma di settori produttivi e aree applicative, in ambito elettrico, meccanico, fluidodinamico e chimico. Lo strumento di Ricerca Rapida vi permetterà di trovare le presentazioni che si riferiscono all'area di vostro interesse.

Residual Stresses and Failure Probability of Solid Oxide Fuel Cells Due to the Sintering Process

F. Greco[1], J. van Herle[1], A. Nakajo[1]
[1]FUELMAT Group, Institute of Mechanical Engineering, Ecole Polytechnique Fédérale de Lausanne, Lausanne, Switzerland

A solid oxide fuel cell (SOFC) is composed of four layers (anode, electrolyte compatibility layer and cathode) of different ceramic materials. The anode layer is produced by tape casting, the remaining layers are deposited by screen-printing. The layers are sintered together at high temperatures. During heating up and cooling down (manufacturing process), stresses are generated in the layers due ...

Simulations of Micropumps Based on Tilted Flexible Structures

M. J. Hancock[1], N. H. Elabbasi[1], M. C. Demirel[2]
[1]Veryst Engineering, LLC., Needham, MA, USA
[2]Pennsylvania State University, University Park, PA, USA

Pumping liquids at small scales is challenging because of the principle of reversibility: in a viscous regime, the flow streamlines through a fixed geometry are the same regardless of flow direction. Recently we developed a class of microfluidic pump designs based on tilted flexible structures that combines the concepts of cilia (flexible elastic elements) and rectifiers (e.g., Tesla pump). We ...

Numerically Closing the Loop of the Adaptive Optics Sensor: the Validation of the COMSOL Multiphysics® Simulation

C. Del Vecchio[1], R. Briguglio[1], A. Riccardi[1]
[1]National Institute for Astrophysics, Arcetri Astrophysical Observatory, Florence, Italy

As any other modelling of a physical behavior, the numerical simulation of the mechanical response of an adaptive secondary mirror requires that the results match the experimental data. Such an agreement was recently demonstrated for the local mirror stiffness of the LBT and VLT Deformable Mirrors; a reliable modeling is a good tool for the extrapolation of the missing optical data (spider ...

Simulation of Hygro Swelling Induced Stresses in Flip Chip Interconnects in a Stress-Sensitive Chip-on-Board Configuration

M. Fretz
Optics & Packaging, CSEM SA, Central Switzerland Center, Alpnach, Switzerland

Flip chip interconnections are used for the direct electrical connection of face-down electronic components like MEMS pressure sensors. The investigated bonding technologies are gold stud bumping in combination with anisotropic conductive adhesives (ACA) and solder ball bumping in combination with underfill in a chip-on-board configuration. The modeled chip is an absolute pressure sensor based on ...

Designing Materials for Mechanical Invisibility Cloaks

P. Olsson[1], F. Larsson[1], A. Khlopotin[1], S. Razanica[1]
[1]Chalmers University of Technology, Gothenburg, Sweden

In solid mechanics, there is considerable interest in achieving “invisibility”. The applications in mechanics include protection of structures and parts of structures from potentially harmful transient waves and steady state vibrations. A suggested large scale application is that protection against seismic waves from earthquakes could be achieved by using cloaking to re-route the waves around ...

A Computational Approach for Optimizing the First Flyer Using COMSOL Multiphysics

A.H. Aziz[1], H. Pourzand[1], A.K. Singh[1]
[1]Pennsylvania State University, University Park, PA, USA

COMSOL Multiphysics software was used to structurally optimize the Wright brothers’ flyer. The flyer was drawn in SolidWorks, imported and meshed in COMSOL. COMSOL Solid Mechanics module was used to analyze the flyer. Four of the sixteen struts were removed yet the structural integrity of the flyer was maintained. COMSOL Laminar Flow module was used to compute the aerodynamic forces and ...

Simulation and Analysis of Two Fans Air Speed Match Design in Off-Road Mine Tract Generator Using COMSOL

Y. Shen[1], D. Wu[1]
[1]Beijing University of Science & Technology, Beijing, China

This paper describes a model of self-ventilated generator cooling on a 170 tons off-road mine dump truck. Considering the space restrictions of mine dump truck, the cooling systems for the generator and the in-wheel motors of the rear axle share one air inlet duct. With the action of generator fan and rear duct fan, cooling air from the inlet duct will be divided into two parts to cool the ...

Modeling Flow and Deformation During Salt-Assisted Puffing of Single Rice Kernels

T. Gulati[1], A. K. Datta[1]
[1]Department of Biological & Environmental Engineering, Cornell University, Ithaca, NY, USA

Puffing of biomaterials involves mass, momentum and energy transport along with large volumetric expansion of the material. Development of physics-based models that can describe heat and moisture transport, rapid evaporation and large deformations can help understand the puffing process. In this context, a fundamentals based study of salt-assisted puffing of rice is described. A multiphase model ...

Analysis to Determine Optimum Strain Gauge Locations for SENSEWHEEL

T. Suzuki[1], C. Holloway[1], S. Taylor[1]
[1]University College London, London, UK

Manual wheelchair users suffer shoulder pain and injury in the long term because of unconscious overuse. The ‘SENSEWHEEL’, which interposes three identical load cells between pushrim and rear wheel, measures the three components of pushing force Fx, Fy and Fz, and axial torque Tx applied at each load cell. Strain gauges were located on a diaphragm forming one face of the load cell. The ...

Mechanical Strength Simulation of Concrete Samples Using COMSOL Multiphysics® Software with 3D Mesh Generated by Industrial Tomography System

W. C. Godoi[1], D. A. Ussuna[2], S. J. Ribeiro[2], K. de-Geus[3], V. Swinka-Filho[2], F. C. de-Andrade[3], K. F. Portella[2], B. L. Medeiros[2], R. C. R. Santos[4]
[1]Universidade Tecnológica Federal do Paraná, Curitiba, PR, Brazil
[2]Institutos Lactec, Curitiba, PR, Brazil
[3]Copel Geração e Transmissão S.A., Curitiba, PR, Brazil
[4]Universidade Federal do Paraná, Curitiba, PR, Brazil

Analysis of concrete structures is usually carried out by destructive methods. The internal volume flaws directly influence concrete properties. Such inclusions are empty or even resulting from the manufacturing process or degradation by percolation leaching dissolution and chemical reactions between its constituents. Industrial tomography systems (ITS), have proved to be a powerful tool for ...
