Modeling of Ultrasonic Transducers and Ultrasonic Wave Propagation for Commercial Applications Using Finite Elements with Experimental Visualization of Waves for Validation - new
D. R. Andrews
Cambridge Ultrasonics, Over, UK
Finite element (FE) modelling of ultrasonic propagation using COMSOL Multiphysics® simulations can be used to create images of waves. Unfortunately, in time-stepping solutions, it is possible for numerical instabilities to grow large and dominate the solution adversely. Any design of transducer that is based upon poorly-configured FE models is unlikely to perform as expected and will almost ...
Lamb Waves and Dispersion Curves in Plates and It’s Applications in NDE Experiences Using Comsol Multiphysics
P. Gómez, J. P. Fernandez, and P. D. García
Hydro-Geophysics & NDE Modeling Unit
University of Oviedo
In this paper, a model for numerically obtaining lamb wave modes and dispersion curves in plates is presented. It is shown that COMSOL Multiphysics can be employed to simulate the behavior of guided waves in dispersive plates, which is useful for NDE applications. A two dimensional steel plate (4x0.1 meters) is excited with a space-time impact point source. To model the point source, we use ...
C. Van der Woude, and S. Narasimhan
University of Waterloo, Waterloo, ON, Canada
This paper presents a study of a wind turbine subjected to wind and seismic loading, carried out using COMSOL Multiphysics. The dynamic properties and response of wind turbine structures are of interest, as recent developments in wind energy have led to the design and construction of increasingly large and flexible turbine structures. A typical turbine structure model was created in ...
Rakesh Kumar Pati , SK Mohammed ali, Sakuntala Mahapatra, Millee Panigrahi
MEMS Design Centre, Dept. of ETC, Trident Academy of Technology, Bhubaneswar, Odisha, India
Despite of the existing successful clinical applications, however, the interaction, i.e. artificial sensing, between the robot and the patient is still very limited. With the help of various cameras, vision is almost the only feeling that a robot can have. In order to imitate the human skin, various signals e.g., the strength of pressure, change of strength, speed and acceleration should be ...
T. Graf, T. Gisler, P. Sollberger, O. Schaelli
School of Engineering and Architecture, Lucerne University, Horw, Switzerland
Axisymmetric acoustic waves propagating along buried water pipes have been investigated by FEM and experimentally. Universal dispersion relations of the fundamental mode were obtained as a function of the standard dimension ratio SDR and of the material surrounding the pipe (soil, air). At low frequency there exists little dispersion and the “dc” phase velocity of the leak noise is independent ...
Simulation of Acoustic Energy Harvesting Using Piezoelectric Plates in a Quarter-Wavelength Straight-Tube Resonator
B. Li, J.H. You
Southern Methodist University, Dallas, TX, USA
An acoustic energy harvesting mechanism at low frequency (~200 Hz) using lead zirconate titanate (PZT) piezoelectric cantilever plates placed inside a quarter-wavelength straight-tube resonator has been studied using COMSOL Multiphysics 4.3 and compared with experimental data. When the tube resonator is excited by an incident wave at its acoustic eigenfrequency, an amplified acoustic resonant ...
H. Bruus, P.B. Muller, R. Barnkob, M.J.H. Jensen
Technical University of Denmark, Kongens Lyngby, Denmark
COMSOL, Kongens Lyngby, Denmark
We have simulated the ultrasound-induced acoustophoretic motion of microparticles suspended in an aqueous solution. The full first-order thermoviscous acoustics equations have been implented on a rectangular microfluidic 2D domain excited with an ultrasound field tuned to resonance near 2 MHz. The micrometer-thin but crucial viscous boundary layers at the rigid walls have been fully resolved. ...
T. G. Zielinski
 Institute of Fundamental Technological Research, Polish Academy of Sciences, Warsaw, Poland
Many of fibrous materials are very good sound absorbers, because the acoustic waves, which propagate in air and penetrate a fibrous layer, interact with the fibers so that the wave energy is dissipated. The dissipation is related to some viscous and thermal effects occurring on the micro-scale level. On the macroscopic level, a fibrous medium can be treated as an effective inviscid fluid, ...
V. Pavelko, I. Pavelko, M. Smolyaninovs, H. Pffeifer, M. Wevers
Riga Technical University, Riga, Latvia
Catholic University Leuven, Leuven, Belgium
A problem of damage prediction in aircraft structure and its non-destructive evaluation is very important for aircraft structural health assessment. The analysis of the features of direct impact of thin-walled laminate component of aircraft was performed by COMSOL Multiphysics software. Mainly the GFRC and CFRC laminates were selected in form either thin separate plate or sandwich structure. The ...
Esaote SpA, Florence, Italy
Pulse-echo FEM simulation is seldom found in literature for ultrasound imaging array probes, since the complete modeling of such device is extremely complicated. Nevertheless, the 2D FEM described in the present work was successful, thanks to the following design procedure (see figure): Two piezoacoustic models were employed, one for transmission of the pressure wave into the acoustic domain, ...
