La Galleria delle Applicazioni raccoglie un'ampia varietà di tutorial e di app dimostrative realizzati con COMSOL Multiphysics in diversi ambiti applicativi, inclusi quelli elettrico, meccanico, fluidico e chimico. E' possibile scaricare i file dei modelli e delle app demo pronti all'uso e le istruzioni step-by-step per costruirli, e utilizzarli come punto di partenza per le proprie simulazioni.
Lo strumento di Ricerca Rapida permette di trovare i modelli che si riferiscono alla propria area di interesse.
Si noti che molti degli esempi qui presentati sono accessibili anche tramite le Librerie delle Applicazioni incorporate nel software COMSOL Multiphysics® e disponibili dal menu File.
Electromagnetic scattering simulation for an object with continuous rotational symmetry can be performed in 2D axisymmetry instead of 3D to drastically reduce computational time and resources. This model shows how to simulate arbitrary plane wave incidence in 2D axisymmetric models by ... Per saperne di più
One of the ways we can simplify and reduce the size and computational complexity of a finite element model is by using any symmetries present in a model. In this entry, you can find three practical examples highlighting how to exploit symmetries in RF or wave optics modeling. They all ... Per saperne di più
The "Smart Radiator Device," a multilayer structure, has the capability to control thermal emissivity at different temperatures. This multilayer structure is lightweight thus finds its application in spacecraft mission. The thermochromic vanadium oxide (VO2) material is the heart of ... Per saperne di più
This proof-of-concept model showcases how to handle a Gaussian beam propagating in the negative y direction in 2D. The model includes several studies, including a parametric sweep, to cover a wide combination of settings describing the background Gaussian beam, such as settings for ... Per saperne di più
Stimulated Brillouin Scattering (SBS) describes a nonlinear interaction between light and sound. In optical fibers, SBS can be detrimental for power or communication purposes, but can be leveraged for sensing applications. The SBS gain spectrum quantifies the optic-acoustic mode ... Per saperne di più
In this model of a single-beam optical trap, SiO2 nanospheres in streaming water pass by or get captured depending on where they are released from. The electromagnetic force on the particles is calculated in the Electromagnetic Waves, Frequency Domain interface, with a Gaussian ... Per saperne di più
In this extension of the model Optical Scattering off a Gold Nanosphere, the transmission spectra due to spherical nanoparticles of gold with varying radii dispersed in glass are computed and mapped onto the CIE 1931 and sRGB colorspaces. For a description of this model, see the ... Per saperne di più
This example demonstrates the usage of the Scattered Field formulation to compute the scattering of light off of a single scatterer on top of a dielectric half-space. It uses the analytic Fresnel equations to design the background field. For a detailed introduction to this model, see ... Per saperne di più
This example of a plasmonic waveguide filter shows that the waveguide rejects the electromagnetic radiation of the wavelength between 1.4 um and 1.6 um, but allows the rest of the wavelength. The silver material can be modeled using the Drude-Lorentz approximation, with ε∞ = 3.7, ωp = 13 ... Per saperne di più
This model simulates a holographic page data storage system. The studies include the recording and retrieval processes. The object beam encrypting 8-bit data is focused into a holographic material by a Fourier lens (Fourier transformation). In the recording process, the object beam ... Per saperne di più
