La Galleria delle Applicazioni raccoglie un'ampia varietà di modelli tutorial e di app dimostrative realizzati con COMSOL Multiphysics in diversi ambiti applicativi, inclusi quelli elettrico, meccanico, fluidico e chimico. E' possibile scaricare i file dei modelli e delle app demo pronti all'uso e le istruzioni step-by-step per costruirli, e utilizzarli come punto di partenza per le proprie simulazioni.

Lo strumento di Ricerca Rapida permette di trovare i modelli che si riferiscono alla propria area di interesse. Per scaricare i file .mph dei modelli è necessario effettuare il login o creare un account COMSOL Access associato a un numero di licenza valido.


Polymerization in Multijet Tubular Reactor

In a polymerization reactor for polyester manufacturing, the mixing in the reactor is achieved by impinging turbulent jets of reactants onto each other. The turbulence affects the reaction kinetics and quality of the polymer linkage. Turbulent flows involving rapid reaction kinetics are quite common in the production of polymers, and the complex interplay between fluid dynamics and fast ...

Boat Reactor for Low Pressure Chemical Vapor Deposition

Chemical vapor deposition (CVD) is an important step in the process of manufacturing microchips. One of the common applications is the deposition of silicon on wafers at low pressure. Low pressure reactors are used to get a high diffusivity of the gaseous species, which results in a uniform deposition thickness, since the process becomes limited by the deposition kinetics. The goal of this ...

Biosensor Design

Surface reactions with adsorption-reaction-desorption steps are common in for example photocatalysis and biosensors. A flow cell in a biosensor contains an array of micropillars for adsorption of for example antigens in aqueous solutions. A signal proportional to the surface coverage can be detected in a sensor, for example through chemiluminescence. This demo app features a flow cell with ...

Carbon Deposition in Heterogeneous Catalysis

Carbon deposition on the surface of solid catalysts is commonly observed in hydrocarbon processing. A known problem is that carbon deposits can impede the activity of catalysts as well as block the flow of gas through a catalyst bed. This example investigates the thermal decomposition of methane into hydrogen and solid carbon, over a catalyst. The influence on the catalyst activity is first ...

Finding Kinetic Arrhenius Parameters Using Parameter Estimation

This example shows how to use the Parameter Estimation and Experiment features in the Reaction Engineering interface for optimization with multiple experimental data input files. The application finds the Arrhenius parameters of a first order reaction where Benzene diazonium chloride decomposes to benzene chloride and nitrogen at 313, 319, 323, 328, and 333 K.

A Multiscale 3D Packed Bed Reactor

One of the most common reactors in the chemical industry, for use in heterogeneous catalytic processes, is the packed bed reactor. This type of reactor is used both in synthesis as well as in effluent treatment and catalytic combustion. This model is set up to calculate the concentration distribution in the reactor gas that flows around the pellets, but it also uses an **extra dimension** that ...

Optimization of a Catalytic Microreactor

In this application, a solution is pumped through a catalytic bed where a solute species reacts as it gets in contact with the catalyst. The purpose of this example is to maximize the total reaction rate for a given total pressure difference across the bed by finding an optimal catalyst distribution. The distribution of the porous catalyst determines the total reaction rate in the bed. A large ...

Porous Reactor with Injection Needle

This application treats the flow field and species distribution in an experimental reactor for studies of heterogeneous catalysis. The model exemplifies the coupling of free and porous media flow in fixed bed reactors. The reactor consists of a tubular structure with an injection tube that has its main axis perpendicular to the axis of the reactor. The incoming species in the main and injection ...

Packed Bed Reactor

One of the most common reactors in the chemical industry, for use in heterogeneous catalytic processes, is the packed bed reactor. This type of reactor is used both in synthesis as well as in effluent treatment and catalytic combustion. The reactor consists in essence of a container filled with catalyst particles. These particles can be contained within a supporting structure, like tubes or ...

Liquid Chromatography

High-performance liquid chromatography (HPLC) is a common method of separating, identifying, and quantifying each chemical compound in a mixture. HPLC is found in the pharmaceutical, biotech, and food industries. The Liquid Chromatography app simulates the separation of two species within a generic liquid chromatography column. Simulations can help pinpoint design elements of chromatography ...

1 - 10 of 53 First | < Previous | Next > | Last
