La Galleria delle Applicazioni raccoglie un'ampia varietà di tutorial e di app dimostrative realizzati con COMSOL Multiphysics in diversi ambiti applicativi, inclusi quelli elettrico, meccanico, fluidico e chimico. E' possibile scaricare i file dei modelli e delle app demo pronti all'uso e le istruzioni step-by-step per costruirli, e utilizzarli come punto di partenza per le proprie simulazioni.
Lo strumento di Ricerca Rapida permette di trovare i modelli che si riferiscono alla propria area di interesse.
Si noti che molti degli esempi qui presentati sono accessibili anche tramite le Librerie delle Applicazioni incorporate nel software COMSOL Multiphysics® e disponibili dal menu File.
Electromagnetic Plunger
This is a transient model of an electromagnetic plunger consisting of a magnetic core, nonmagnetic guider, multi-turn coil, and magnetic plunger attached to the spring and damper at the far end. The electromagnetic force on the plunger due to the transient current in the coil is ... Per saperne di più
Multi-Turn Coil Winding around a Ferromagnet
A demo model of a 50 Hz AC coil wound around a ferromagnetic (linear) core. The model is intended as a tutorial to show how to create a relatively complex geometry and set up the new Multi-Turn Coil features for the simulation. The model requires the Design module to fillet the edges of ... Per saperne di più
Operational Amplifier with Capacitive Load
An operational amplifier (op-amp) is a differential voltage amplifier with a wide range of applications in analog electronics. This tutorial models an op-amp connected to a feedback loop and a capacitive load. The op-amp is modeled as an equivalent linear subcircuit in the Electrical ... Per saperne di più
Electrodynamic Wheel Magnetic Levitation in 2D
This model illustrates the working principle of an electrodynamic wheel (EDW) magnetic levitation system. EDW magnetic levitation system consists of rotating and/or translationally moving permanent magnet Halbach rotor above a passive conducting guideway/track. Eddy current is ... Per saperne di più
The epitaxial growth of SiC by PVT method
Silicon Carbide (SiC) Epitaxial Furnace is a specialized equipment for the production and preparation of SiC Epitaxial Wafers. This model demonstrates the process of preparing SiC Epitaxial Wafer based on the Physical Vapor Transport (PVT) method in a furnace. This involves heating the ... Per saperne di più
Thin Low Permittivity Gap Comparison
The thin low permittivity gap boundary condition is meant to approximate a thin layer of material with low relative permittivity compared to its surroundings. This boundary condition is available for electrostatic field modeling. This example compares the thin low permittivity gap ... Per saperne di più
Analyzing Electric Motor and Generator Designs
This is a primer model of a permanent magnet machine. It is a generic model that can be modified to simulate a motor or generator. It demonstrates different capabilities of COMSOL Multiphysics® to examine aspects of machine design, such as air gap magnetomotive force (MMF), ... Per saperne di più
Eddy Currents in a Cylinder
The eddy currents in a conductive cylinder, generated from currents passing through a surrounding coil, are studied. The skin effect in the coil is also studied. Per saperne di più
Magnetic Prospecting of Iron Ore Deposits
Magnetic prospecting is a geological exploration method that is applicable to certain types of iron ore deposits, in particular those made up of magnetite and hematite. The method consists of measuring the magnetic anomalies (changes in the earth's magnetic field) due to the presence of ... Per saperne di più
Axial Field Magnetic Gear in 3D
In this model, an axial field magnetic gear with a gear ratio of 5:2 is modeled. Both the high speed and low speed rotors consist of permanent magnet and back iron. The low speed rotor consists of five pole-pairs, while the high speed rotor consists of two pole pairs, and the stationary ... Per saperne di più
