Image Gallery

Welcome to the COMSOL Image Gallery. The simulation images on this page are available for editors and journalists to use in appropriate articles. The phrase "Image made using COMSOL Multiphysics® and provided courtesy of COMSOL®." must appear in the vicinity of every image or at the bottom of the article.

For all other uses you must contact COMSOL directly through www.comsol.com/contact/
or by writing to .


COMSOL Server

Application Library

Application Library

The COMSOL Server™ Application Library displays all of the available applications for a user's account. From the library, the user may launch applications and mark favorites.

Administration

Administration

The Administration section of COMSOL Server™ enables administrative users to monitor applications and create and edit groups, used for organizing application deployment within departments, across companies, and around the world.

Build and Run Simulation Apps

Build and Run Simulation Apps

The Application Builder allows COMSOL Multiphysics® software users to build an intuitive interface around their COMSOL model that can be run by anyone, even those without prior simulation experience. COMSOL Server™ is the engine for running apps and the hub for distribution, allowing engineering teams and production departments to share applications throughout organizations and worldwide.

App Distribution

App Distribution

Once an app is created with the Application Builder available in COMSOL Multiphysics®, COMSOL Server™ provides engineers and researchers with a cost-effective solution for managing how the app is accessed and used, both within an organization and worldwide.

From Model to App

Heat Exchanger Performance Study App

Heat Exchanger Performance Study App

Application of an air-filled shell and tube heat exchanger with water flowing through the inner tubes. Results reveal temperature distribution, pressure drop, and the equivalent heat transfer coefficient of the exchanger for the desired operating conditions chosen by the user.

Thermal Lensing Simulator App

Thermal Lensing Simulator App

This application was created from a model of a high-power industrial fiber laser system. With this thermal lensing app the user can analyze the heat generated in the lens, which can alter ray trajectories by inducing thermal deformation or changing the refractive index of the material.

Halbach Rotor Simulator App

Halbach Rotor Simulator App

This application was created using a model of a Halbach rotor and the Application Builder available in COMSOL Multiphysics®. The user can test different rotor geometries and analyze the resulting magnetic field distribution.

Apps

Gas Box Designer App

Gas Box Designer App

This application computes the back pressure in a network of pipes fed by a system of mass flow controllers (MFC). Each MFC supplies a given flow rate to one of the pipes, and can only function correctly if the back pressure remains below 760 Torr. Users can obtain results for chosen pipe dimensions, boundary conditions, and fluid model.

Tubular Reactor Simulator App

Tubular Reactor Simulator App

This application was created using a model of the reaction kinetics in a tubular reactor. Users may alter the reactor properties and boundary conditions in order to analyze the temperature and conversion profiles resulting from the exothermic reaction.

Tuning Fork App

Tuning Fork App

This application computes the fundamental mode and resonant frequency for a tuning fork. The app can also find the length of the prongs for a given target frequency. For example, this tuning fork vibrates at 440 Hz, or standard concert pitch, when its prong length is 81.34 mm.

Microwave Oven Designer App

Microwave Oven Designer App

This app helps users design a microwave oven by testing parameters such as the oven geometry, food characteristics, and microwave power settings. Application results show the temperature at different control points in the food.

Three-Cylinder Reciprocating Engine App

Three-Cylinder Reciprocating Engine App

This model of a three-cylinder reciprocating engine is turned into an application where the user can change operating parameters to predict the resulting force and stress in the engine components.

RF MEMS Switch - Pull-in Analysis App

RF MEMS Switch - Pull-in Analysis App

This application is based on a model of a thin micromechanical bridge suspended over a dielectric layer. The user can obtain the contact force and displacement for a chosen voltage, stiffness, contact force, and bridge configuration.

Wastewater Contaminant Removal Simulation App

Wastewater Contaminant Removal Simulation App

This application was created from a model of a wastewater treatment system that analyzes the fluid flow and mixing properties in a secondary clarifier. The user can compare different design results based on inputs for geometry, mixture properties, and flow boundary conditions.

Self-Focusing Gaussian Beam App

Self-Focusing Gaussian Beam App

Application from a model of a self-focusing Gaussian beam created using a lens with an intensity-dependent index of refraction. The user can test the simulation results for different wavelengths, material properties, and peak intensities

Heat Exchanger Performance Study App

Heat Exchanger Performance Study App

Application of an air-filled shell and tube heat exchanger with water flowing through the inner tubes. Results reveal temperature distribution, pressure drop, and the equivalent heat transfer coefficient of the exchanger for the desired operating conditions chosen by the user.

Halbach Rotor Simulator App

Halbach Rotor Simulator App

This application was created using a model of a Halbach rotor and the Application Builder available in COMSOL Multiphysics®. The user can test different rotor geometries and analyze the resulting magnetic field distribution.

Thermal Bridge Verification App

Thermal Bridge Verification App

With this application of a thermal bridge, the user may obtain temperature and heat flux data by testing different combinations of geometry, materials, and boundary conditions.

Thermal Lensing Simulator App

Thermal Lensing Simulator App

This application was created from a model of a high-power industrial fiber laser system. With this thermal lensing app the user can analyze the heat generated in the lens, which can alter ray trajectories by inducing thermal deformation or changing the refractive index of the material.

Load Lock Vacuum System App

Load Lock Vacuum System App

Application for studying the adsorption and desorption of water in a load-lock vacuum system. Results show the pressure in the vacuum chamber and load lock segments when the user has specified the desorption time, density, and sticking coefficient.

Mach-Zehnder Modulator App

Mach-Zehnder Modulator App

This application is based on a model of a Mach-Zehnder interferometer and directional couplers used to control the output amplitude and phase of the light passing through the modulator. The app allows the user to compare results of different waveguide designs and boundary conditions by changing the waveguide shape, material properties, and electrical input.

Decorative Electroplating Simulator App

Decorative Electroplating Simulator App

This application allows the user to analyze the thickness of the deposited layer during an electroplating process. Results show the change in electrode thickness for chosen material, electrolyte properties, and deposition time.
