Presentazioni e Articoli Tecnici

In questa sezione troverete i lavori presentati alle Conferenze mondiali COMSOL. Le presentazioni descrivono ricerche e prodotti innovativi progettati con COMSOL Multiphysics da colleghi di tutto il mondo. I temi delle ricerche presentate abbracciano un'ampia gamma di settori produttivi e aree applicative, in ambito elettrico, meccanico, fluidodinamico e chimico. Lo strumento di Ricerca Rapida vi permetterà di trovare le presentazioni che si riferiscono all'area di vostro interesse.

Multiphysics Analysis of Normal Conducting RF Cavities for High Intensity Proton Accelerators

M. Hassan[1], I. Gonin[1], T. Khabiboulline[1], V. Yakovlev[1]
[1]Fermi National Accelerator Laboratory, Batavia, IL, USA

Normal conducting cavities are typically used in the front end of proton accelerators to get the beam accelerated to velocities approximately a few tenths of the speed of light, where superconducting cavities can then be used to accelerate the beam to the speed of light. The warm part of a typical proton accelerator would contain a radio frequency quadrupole (RFQ) and several buncher cavities. ...

Resonances in Tapered Double-Port TEM Waveguides

J. Kaerst
HAWK, Fachhochschule Hildesheim/Holzminden/Göttingen, Germany

In this paper resonances in tapered double-port TEM waveguides are used as benchmark for simulations. FEM simulations with COMSOL Multiphysics® and simulations using generalised telegraphist's equations with MATLAB® are compared to ananalytical method capable of calculating the resonances of higher order modes. It is valid for tapered double-port TEM waveguides with constant ...

Calculations of the FMR Spectrum in 1D Magnonic Crystals

M. Mruczkiewicz[1], M. Krawczyk[1], V.K. Sakharov[2], Yu. V. Khivintsev[2], Yu. A. Filimonov[2], S. A. Nikitov[3]
[1]Nanomaterials Physics Division, Faculty of Physics, Adam Mickiewicz University, Pozna?, Poland
[2]Kotel’nikov Institute of Radio Engineering and Electronics, Russian Academy of Sciences (Saratov Branch), Saratov, Russia; Laboratory “Metamaterials”, Chernyshevsky Saratov State University, Saratov, Russia
[3]Kotel’nikov Institute of Radio Engineering and Electronics, Russian Academy of Sciences, Moscow, Russia; Laboratory “Metamaterials”, Chernyshevsky Saratov State University, Saratov, Russia

FMR spectra of the periodic microstructures (one-dimensional magnonic crystals, 1D MCs) were obtained using COMSOL with use partial differential equation interface. Results of these calculations were successfully compared with an experimental data for Damon-Eshbach (DE) and Backward-Volume (BV) geometries. The presented tool allows to analyze periodic structures with various geometries and ...

S-parameter Sensitivity Analysis of Waveguide Structures with FEMLAB

Li, D., Nikolova, N.K.
Computational Electromagnetics Research Laboratory, Department of Electrical and Computer Engineering, McMaster University, Hamilton, Ontario

For the purpose of accurate and efficient design of a microwave structure, sophisticated optimization techniques are typically used. The optimization process can greatly benefit from the availability not only of the objective function, but also its gradient. Numerical electromagnetic solvers do not provide the gradient information, thus defaulting to the finite-difference approximation at the ...

Analysis of RF Characteristics of a Compound Semiconductor Device Integrated with a Wide-Band Antenna for THz Wireless Communications

A. Tashiro[1], M. Nakamura[1], M. Suhara[1]
[1]Tokyo Metropolitan University, Hachioji City, Tokyo, Japan

Use of the terahertz(THz) region, which is unexplored frequency band, is investigated and expected for the next-generation high-speed wireless communication. In this presentation, we propose a monolithic integrated device by using mesa-shaped compound semiconductor and a thin-metal broadband antenna which is capable in THz operation, and we analyze several characteristics of the device by using ...

Simulation of Realistically Shaped Nanoantennas Using COMSOL Multiphysics

C. Moosmann, G. Sigurdsson, K. Dopf, M. D. Wissert, H.-J. Eisler, and U. Lemmer
Light Technology Institute
Karlsruhe Institute of Technology
Karlsruhe, Germany

Nanoantennas – nanometer sized gold structures resonant at optical wavelengths have interesting properties for many applications. For numerical simulations of such structures simplified geometries are usually considered. However the fabricated shapes still differ significantly from perfect geometries and such structures are sensitive to geometrical changes. Here, we investigate how the ...

Going beyond Axisymmetry: 2.5D Vector Electromagnetics

Y.A. Urzhumov[1][,][2], N.I. Landy[1][,][2], C. Ciraci[2], D.R. Smith[1][,][2]
[1]Department of Electrical and Computer Engineering, Pratt School of Engineering, Duke University, Durham, NC, USA
[2]Center for Metamaterials and Integrated Plasmonics, Pratt School of Engineering, Duke University, Durham, NC, USA

Linear wave propagation through inhomogeneous structures of size R?? (Fig.1) is a computationally challenging problem, in particular when using finite element methods, due to the steep increase of the number of degrees of freedom as a function of R/?. Fortunately, when the geometry of the problem possesses symmetries, one may choose an appropriate basis in which the stiffness matrix of the ...

Analysis of Electromagnetic Propagation for Evaluating the Dimensions of a Large Lossy Medium

A. Pellegrini[1] and F. Costa[1]
[1]ALTRAN Italia, Pisa, Italy

In this paper the propagation of a plane wave in a large lossy medium is presented. The investigated geometry consists in a wedgeshaped lossy dielectric embedded in a lossy material with different electromagnetic properties. The aim of the study is to determine the feasibility of a radar technique for measuring the length of the dielectric wedge. In order to address this problem and to evaluate ...

Modeling of Drying of Cellular Ceramic Structures: Coupled Electromagnetic and Multiphase Porous Media Model

A. Dhall[1], G. Peng[2], G. Squier[2], M. Geremew[3], L. Bogaczyk[2], J. George[3], W.A. Wood[3], and A.K. Datta[1]
[1]Biological and Environmental Engineering, Cornell University, Ithaca, New York, USA
[2]Manufacturing Technology & Engineering, Corning Inc., Sullivan Park, Corning, New York, USA
[3]Corporate Research, Corning Inc., Sullivan Park, Corning, New York, USA

Cellular ceramic substrates are extensively used for pollution control systems in vehicles. The manufacturing process of them can involve microwave drying. In this study, we describe the development of a modeling framework for the microwave drying process of these substrates. The transport model is implemented in COMSOL 3.5a using 4 PDEs: 1) Convection-Conduction for temperature, 2) ...

Modeling Microwave Chiral Material Based On Crank Resonators Arrays Using COMSOL Multiphysics

J. Muñoz[1], G.J. Molina [1], M.M. Rojo[1]
[1]Dpto. Electromanetismo y Electrónica, Facultad de Química, Universidad de Murcia, Campus Espinardo, Murcia, Spain

Electromagnetic metamaterials present exotic and unusual properties hardly to be found in nature with many potential applications. They are usually built by distributing small resonant structures in periodical lattices. If the structure has chiral symmetry, the medium is called chiral metamaterial. Here the electrodynamics behavior of a chiral structure with a huge electromagnetic activity at ...
