Galleria dei Modelli

La Galleria dei Modelli raccoglie un'ampia varietà di modelli realizzati con COMSOL Multiphysics in diversi ambiti applicativi, inclusi quelli elettrico, meccanico, fluidico e chimico. E' possibile scaricare i file .mph dei modelli pronti all'uso e le istruzioni step-by-step per costruirli, e utilizzarli come punto di partenza per le proprie simulazioni. Lo strumento di Ricerca Rapida permette di trovare i modelli che si riferiscono alla propria area di interesse. Per scaricare i file .mph dei modelli è necessario effettuare il login o creare un account COMSOL Access associato a un numero di licenza valido.

Fluid-Structure Interaction in Aluminum Extrusion

In massive forming processes like rolling or extrusion, metal alloys are deformed in a hot solid state with material flowing under ideally plastic conditions. Such processes can be simulated effectively using computational fluid dynamics, where the material is considered as a fluid with a very high viscosity that depends on velocity and temperature. Internal friction of the moving material acts ...

Convection Cooking of Chicken Patties

When cooking food, such as a patty, in convection ovens there is a trade off in the heating method. If the patty is heated at a low oven temperature the cooking is slow and the patty dries out, resulting in a poor taste. If the patty is heated rapidly at a high temperature, it is difficult to get an even temperature in the patty. When the core is cooked the crust may be over-cooked. This ...

Thermo-Photo-Voltaic (TPV) Cell

This model illustrates an application that maximizes surface-to-surface radiative fluxes and minimizes conductive heat fluxes. A thermo-photo-voltaic (TPV) cell generates electricity from the combustion of fuel and through radiation. The fuel burns inside an emitting device that radiates intensely. Photo-voltaic (PV) cells—almost like solar cells—capture the radiation and convert it to ...

Condensation Detection in an Electronic Device

This example simulates the thermodynamical evolution of moist air in an electronic box with the aim of detecting whether condensation occurs when the external environment properties change. The model imports measured data for the air temperature, pressure, and water vapor concentration. For the first part of the simulation, the water vapor concentration is considered to be homogeneous inside the ...

Thermal Stress Analysis of a Turbine Stator Blade

The conditions within gas turbines are extreme. The pressure can be as high as 40 bar, and the temperature more than 1000 K. Any new component must therefore be carefully designed to be able to withstand thermal stresses, vibrations and loads asserted by the fluid rushing through the turbine. If a component fails, the high rotational speeds can result in a complete rupture of the whole ...

Surface Resistor: Thermo-Mechanical Analysis

The drive for miniaturizing electronic devices has resulted in today’s extensive use of surface-mount electronic components. An important aspect in electronics design and the choice of materials is a product’s durability and lifetime. For surface-mount resistors and other components producing heat it is a well-known problem that temperature cycling can lead to cracks propagating through the ...

Cooling and Solidification of Metal

This example is a model of a continuous casting process. Liquid metal is poured into a mold of uniform cross section. The outside of the mold is cooled and the metal solidifies as it flows through. When the metal leaves the mold, it is completely solidified on the outside, but still liquid inside. The metal will continue to cool and eventually solidify completely, at which point it can be cut ...

Turbulent Flow Through a Shell-and-Tube Heat Exchanger

This model studies a part of a shell-and-tube heat exchanger where hot water enters from above. The cooling medium flows through the tubes that, in this model, impose a constant temperature at the walls. Furthermore, the tubes are assumed to be made of stainless steel and the heat flux is also modeled through them. The purpose of the model is to show the coupling between the k-omega turbulence ...

Heating of a Flow in a Heat Exchanger Unit Cell

In this example, we study the transport by convection and conduction. Such a system may be found in a heat exchanger or in heating of endothermic reactors. The fluid flow enters the unit cell from below and the fluid is heated as it passes the heated cylinder. Since the problem is symmetric, we only need to treat half of the unit cell. We vary the flow rate, using the parametric solver, in ...

Heat Transfer in a Thin Plate

This example models heat transfer in a thin rectangular metal plate. Because the plate’s thickness is only 1/100 of its length and width, you can simulate the process using a 2D approximation. The plate has a fixed temperature at one end and is isolated at the other. A surrounding liquid cools the plate by convection. In addition, the model considers surface-to-ambient radiation.
